FLOATING SKIMMER ASSEMBLY AND INSTALLATION
1. Following the instructions shown in #1
assemble parts 1 through 4 in the parts
list above.
2. Following the instructions shown in #2
assemble the skimmer body, parts 9,
11, and 12, and attach the hose to the
bottom of the skimmer body.
3. Following the instructions shown in #3,
#4 & #5 attach the skimmer body to
the hook assembly. Connect the loose
end of the hose to the intake to pump
connection tting and hang on the wall.
4. Following the instructions shown in #4,
connect the skimmer to the over the wall
hook and water adjustment bar. Let the
skimmer hang from the hook and bar.
5. When everything is assembled and
installed you can adjust the height of
the skimmer body on the water level
adjustment bar, as shown in #4. The top
of the skimmer body should be about an
inch below the water level if you want it
locked at one height. Or, you can let the
skimmer body oat up and down as the
water level in the pool changes.
6. Following the instructions shown in #6,
install the skimmer basket and tank body
cover, parts 5, 6 ,7, and 8.
7. Connect the lter and pump hoses to
the intake to pump connection and the
water return connection.
8. Make sure that the top hose is for water
return to the pool from the lter/pump
and the bottom hose is for water intake
to the lter/pump.
WARNING: Never let the water level drop
below the top of the skimmer body. If
this happens water will stop owing into
the lter and the pump may burn out. A
burned-out pump due to no water ow is
not covered under the lter warranty.
