1. PLACE AIR CONDITIONER
2. PLACE WINDOW BEAM 3. CONNECT HOSE 1
Slide the air conditioner connector
downwards into the designated slots at the
back of the air conditioner until you hear a
click sound.
Make sure the plastic hook of the connector
is at the top.
Open the sliding window so there’s enough
room to place the window beam
.
Adjust the window beam to the desired
width (min. 67.5cm, max. 123cm) and place
it in the opening of the window.
Close the window so the window beam
remains fixed.
Attach the window beam connector
to
the round hole in the window beam
.
You’ll know it’s properly attached when you
hear a click sound.
Plug the connector into a 220-240V/50Hz
socket.
Press the POWER button.
Want more information on how the air
conditioner works? Read the extended
manual.
Extend the drain hose
by about 10cm on
both sides.
Rotate the connectors
and
clockwise
to connect them to the ends of the drain
hose
.
Carefully extend the drain hose
in its
entirety.
Need help?
Call 010 798 89 99
Coolblue.nl/en/customer-
service
Minimum space.
Don’t use the air conditioner
in a room smaller than 10m².
Put the air conditioner in an upright position
and on a sturdy and even surface.
Place the air conditioner near a window and
socket.
Keep a free space of 50cm around the air
conditioner.
Always keep the air
conditioner in an upright
position.
Didn’t manage to keep it
upright after all? Wait 2
hours before use.
CBL1170/CBL1171
4. CONNECT HOSE 2
5. CONNECT HOSE 2 6. TURN IT ON
Follow all instructions as described here.
Always let experts handle repairs, or the
warranty will be voided and we won’t be
liable. at would be a waste of your purchase.
Coolblue isn’t liable for any injury, damage, or
cold toes as a result of incorrect installation.
10m
CHECK.
You’re 50% there.
