Why does my Bluegrass Living Gas Heater smell like gas?
A gas odor during combustion may be due to foreign matter between the control valve and burner. In this case, you should take apart the gas tubing and remove any foreign matter. Alternatively, it could be due to a gas leak, so locate and correct all leaks.
What to do if my Bluegrass Living Gas Heater pilot lights but flame goes out?
If the ODS/pilot lights but the flame goes out when you release the control knob, it could be due to several reasons: 1. The control knob is not fully pressed in, so ensure you press it fully. 2. The control knob is not pressed in long enough; after the ODS/pilot lights, keep the control knob pressed in for 30 seconds. 3. The equipment shutoff valve is not fully open, so fully open the equipment shutoff valve. 4. The thermocouple connection is loose at the control valve, so hand tighten it until snug, and then tighten 1/4 turn more. 5. The pilot flame is not touching the thermocouple, which allows the thermocouple to cool, causing the pilot flame to go out. 6. The thermocouple is damaged, so replace the thermocouple. 7. The control valve is damaged, so replace the control valve.
What to do if my Bluegrass Living Gas Heater has a gas odor even when off?
If you notice a gas odor even when the control knob is in the OFF position, it could be caused by a gas leak. Locate and correct all leaks. It may also indicate a defective control valve, which would need to be replaced.
What to do if my Bluegrass Living Gas Heater burner does not light?
If the burner(s) does not light after the ODS/pilot is lit, it could be because the burner orifice is clogged, so clean the burner orifice. Alternatively, the inlet gas pressure may be too low, in which case you should contact your local gas supplier.
Why is there no spark in my Bluegrass Living Gas Heater?
If there is no spark at the ODS/pilot when the ignitor button is pressed, it could be due to several reasons: 1. The ignitor electrode is positioned wrong or broken, so replace the pilot assembly. 2. The ignitor electrode is not connected to the ignitor cable, so replace the ignitor cable. 3. The ignitor cable is pinched or wet, so free the ignitor cable if it is pinched and keep it dry. 4. The ignitor cable is broken, so replace the ignitor cable. 5. The piezo ignitor is bad, so replace the piezo ignitor.
What to do if Bluegrass Living Gas Heater produces yellow flame?
A high yellow flame during burner combustion could be due to not enough air. Check the burner for dirt and debris and clean it if necessary. It may also be caused by a defective gas regulator, which would need to be replaced. Finally, it could be due to inlet gas pressure being too low, so contact your local gas supplier.
What to do if Bluegrass Living Gas Heater produces unwanted odors?
If your heater produces unwanted odors, it could be due to several reasons: 1. The heater is burning vapors from paint, hair spray, glues, etc., so ventilate the room and stop using odor-causing products while the heater is running. 2. There is a gas leak, so locate and correct all leaks. 3. There is a low fuel supply (propane/LP gas only), so refill the supply tank (Propane/LP models).
Why does my Bluegrass Living Gas Heater shut off?
If your heater shuts off during use and the ODS operates, it could be due to: 1. Not enough fresh air being available, so open a window and/or door for ventilation. 2. Low line pressure, so contact your local gas supplier. 3. The ODS/pilot being partially clogged, so clean the ODS/pilot.
What to do if my Bluegrass Living Gas Heater has delayed ignition?
If you're experiencing delayed ignition of the burner(s), it could be due to low manifold pressure, so contact your local gas supplier. It may also be caused by a clogged burner orifice, so clean the burner.
What to do if Bluegrass Living Gas Heater burner backfires?
If the burner is backfiring during combustion, it could be because the burner orifice is clogged or damaged, so clean the burner orifice. It may also be due to a damaged burner, in which case you should contact customer service. Finally, a damaged gas regulator could be the cause, so replace the gas regulator.
Details requirements for agencies qualified to install and service gas appliances.
Provides technical specifications for different heater models, including BTU, gas type, and dimensions.
Highlights key features of the heater, such as safety pilot and thermostatic control.
Advises adherence to local building and gas codes for installation and operation.
Outlines essential steps and checks before proceeding with the heater installation.
Provides instructions for safely removing the heater from its packaging.
Explains the production of water vapor by unvented heaters and mitigation steps.
Details the importance of fresh air for combustion and ventilation for safe operation.
Specifies minimum safe distances from the heater to combustible materials during installation.
Provides guidelines for choosing the optimal and safe location for installing the heater.
Explains methods and steps for securely mounting the heater to a wall using a bracket.
Instructions for attaching and securing the heater to the floor using base feet.
Details the procedure for safely connecting the heater to the natural gas or propane supply.
Provides steps and warnings for testing all gas piping and connections for leaks.
Details requirements for adequate combustion and ventilation air for safe heater operation.
Crucial safety information and warnings to read before attempting to light the heater.
Step-by-step guide on how to safely ignite the pilot and main burner of the heater.
Explains how the thermostat controls the heater's operation and comfort levels.
Procedure for lighting the pilot using a match if the ignitor fails.
Describes the correct and incorrect pilot flame patterns and their implications.
Details correct and incorrect burner flame patterns, including issues like yellow tipping.
Instructions for inspecting and cleaning the main burner for optimal performance and to prevent soot.
Guidance on cleaning burner components like injectors and pilot air inlets for proper operation.
Cleaning procedures for the Oxygen Depletion Sensing (ODS) pilot assembly.
Instructions for cleaning the exterior of the heater cabinet.
Covers problems with sparking but no ignition, pilot failure, and burner ignition failures.
Addresses delayed ignition, backfiring, yellow flames, whistling, and clicking noises.
Troubleshooting for gas odors, smoke, white powder residue, and heater shut-off due to ODS.
Addresses issues related to insufficient ventilation air causing condensation or odors.
Provides hints for common issues when gas pressure is too low, affecting pilot and burner performance.
Lists replaceable parts for B10TNIR-B and B10TPIR-B models with corresponding part numbers.
Provides part lists for B20/B18/B30/B28TNIR-BB/TPIR-BB heater models.
Information on obtaining replacement parts covered under the product's warranty.
Guidance on how to purchase replacement parts that are not covered by the warranty.
Details about the optional equipment shutoff valve accessory and its specifications.
Information on available installation kits, including flexible connectors and shutoff valves.
Details the terms and conditions of the limited warranties for new and reconditioned products.
Common terms applicable to all Bluegrass Living warranties, including exclusions and limitations.
General| Model | B10TNIR-B |
|---|---|
| Category | Gas Heater |
| Fuel Type | Natural Gas |
| BTU Output | 10, 000 BTU |
| Vent Type | Vent-Free |
| Heating Area | Up to 300 sq. ft. |
| Oxygen Depletion Sensor (ODS) | Yes |
| Weight | 18 lbs |
| Ignition Type | Piezo |
| Mounting | Wall Mount |
