high. designed to achieve good
sonic performances hums a bit
when the volume of the
amplifier is increased. That is
normal and strongly
noticeable especially without
music and with MC gain unit
selection.
The tone arm and cartridge are
not properly installed
Install them well. Eventually
a tone arm cable problem can
occur; please check other
ways out
The cartridge gain is wrong. Select the cartridge gain
following the manufacturer
instructions
The interconnect input and/or
output cables are not shielded.
Be sure to always use shielded
cables for Phono Stage
connections.
SWITCHING ON/OFF
BUMP
The Phono Stage bumps
any time is switched ON or
OFF
It is important to notice that it
does not produce any risk even
if the bump is high
PHONO STAGE (THE)
DOES NOT WORK WHEN
THE PHONO STAGE IS
SWITCHED ON
The AC Phono Stage plug is
disconnected from the AC wall
plug
Connect it being sure that the
AC wall plug works
The Phono Stage just
does not work
The interconnect cables are not
properly connected to the
Phono Stage.
Connect them properly
The fuse is blown Substitute the fuse with one of
the same value
Be sure you selected the right
Input on the amplifier
The electrical connection inside
the Phono Stage could be
damaged
Contact your dealer for
assistance
Troubleshooting 8
PHONO 2 Italian Prestige phono stage
F.A.Q.
Adjustment
PHONO 2 Phono Stage
ACTION DESCRIPTION HOW TO ADJUST IT
MATCHING THE CARTRIDGE
IMPEDENCE
Your cartridge needs a proper
IMPEDANCE matching to
chose between 470ohm or
47Kohm.
Once you disconnect the Phono Stage from the
AC plug Once you disconnect the Phono Stage
from the AC plug remove, taking extreme care,
the acrylic circular bottom. The signal cables are
soldered to the connectors of such bottom so
please doing that operation with great attention.
Inside the Phono stage is visible the RED PCB
where a DIPSWITCH with 4 switches is installed.
