Technical specifications
Type
Constant current and voltage control system with timer
interventions
CC-MODE: Output current 4900mA ± 1%
CC-MODE: Vmax 16800 ± 50mV (0.3%)
CV-MODE: Vmax 16800 ± 50mV (0.3%)
CV-MODE: Cutoff current 150mA ± 10mA
Short circuit protection Available
Overcharge protection Available
Overtemperature protection Available
LEDS 3 colour type for BAT1, BAT2, BAT3, BAT4 and AUX
Special features IPCS and CTP
Auxiliary power 13.8V 110W (max)
Power supply
AC mains 100V - 240V ~, 47 - 63 Hz autoselect
Fuse 1 x 220V 2.5A (5x20mm quick blow) + 1 spare
Power consumption 100W max / 90W typical
Operating temperature range 0°C - 45°C
Storage temperature range -20°C - 65°C (-4°F - 149°F)
Dimensions 170 x 150 x 280 mm
Weight 2200g
The CVS4X underwent and has successfully passed CE
certification.
