AUX output LED indications
# OPERATING MODE LED INDICATION
1
The AUX output is correctly powered up:
30mA < I < 8.0A ~ 8.2A
AUX OK:
AUX LED Steady GREEN
2
The AUX is self-protected if a load is connected and
an excessive current is absorbed:
I > 8.2A
SHORT-CIRCUIT:
AUX LED Steady ORANGE
3
An Overload condition may occur when the AUX is
powered up and an excessive current is drained as
follow:
i) 8.2A < I < 9.5A, for 30sec
ii) 9.5A < I < 13A, for 1sec
iii) I > 13A
OVERLOAD1:
AUX LED+BAT2 Steady RED
OVERLOAD2:
AUX LED Steady RED
OVERLOAD3:
AUX LED Steady ORANGE
