Please make sure that you read these instructions carefully in order to avoid injury when
using the nut riveter. Follow all health and safety rules and regulations. If in doubt and
available please contact a more knowledgeable source.
DO NOT use if damaged.
• Maintain tool in good and clean condition for best and safest performance.
• Keep the work area clean, uncluttered and ensure there is adequate lighting.
• Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip
shoes.
• Keep children and unauthorised persons away from the work area.
• If the riveter is damaged do not use.
• NEVER leave the riveter unattended. When you have finished using the riveter it should
be stored away in a safe place that is out of reach of children.
• NEVER try to get the riveter to perform a task that it was not made for. Do not overload
or misuse the tool.
• ALWAYS dress appropriately – clothing should be close fitted and long hair tied back.
Jewellery should be removed and shoes should be worn with a non-slip sole.
• ALWAYS wear the correct eye or face protection when operating the riveter.
• ALWAYS wear approved respiratory protection. This will help protect you from
any dust.
• ALWAYS ensure you work in a well ventilated room.
• ALWAYS ensure that adjusting keys and wrenches have been removed before using the
tool. If a key or wrench is still attached when the tool is in use this could cause damage
to property or cause injury.
• NEVER operate the tool if you are under the influence of drugs or alcohol as this can
be dangerous.
02
Safe use (continued)
• DO NOT operate the riveter if you are tired as this could be dangerous.
• DO NOT get the riveter wet. Always use in dry locations/conditions.
• ALWAYS check and adhere to national regulations when disposing of the riveter.
Introduction
The BlueSpot 86 PCE Nut Riveter Kit (M3-M8) is supplied with eighty nut rivets and five
riveting nozzle sets. The riveter is ideal for the application of steel and aluminium rivet nuts.
Supplied in a plastic carrying box.
Operation
Note – We always recommend testing this first on a test piece of material until you
become comfortable operating the nut riveter.
1. On the workpiece drill the recommended diameter hole for the threaded insert.
2. Choose the matching mandrel and nose piece from the nut riveter kit.
3. Keep the wrench around the nut riveter handles so they are held in place. Screw the
mandrel into the head (this is a left handed thread).
4. Remove the wrench.
5. Tighten the mandrel so it is tight and secure. The wrench will not allow for the mandrel
to be overtightened.
6. Hold the nut riveter handle in the closed position. Screw on the nosepiece.
7. Release the handle. With the flange end first, screw on the threaded insert.
8. Set the depth screw to the desired length.
9. Insert the threaded insert through the hole. The flange should be flush against the
workpiece.
10. Squeeze the handle of the nut riveter. The threaded insert should form a bulge against
the back of the workpiece. The depth adjustment screw can be adjusted to achieve the
bulge if needed.
11. Release the handle fully.
12. Remove the mandrel from the threaded inset by turning the mandrel adjustment
knob clockwise.
13. Secure your object by screwing a bolt to the threaded insert you have just installed.
