6 - Troubleshooting
Error Cause Solution Comment
Drilling depth does
not match
Drilling depth set incorrectly Correct drilling depth setting See point 2.1.5
Drilling length does not match
Drill bits not completely pushed into the
chuck
Work piece thickness does not corre-
spond to the given value (e.g. 15 mm
instead of 16 mm)
Assembly machine is driving against an
object (e.g. swivel stop)
Drilling length set to 57 mm
Clean dirt from chuck and completely insert
drill bit
Check work piece thickness, correct drilling
depth setting, use drill depth stop
Remove object
See point 2.1.2
See chapter 2
See chapter 2
none
Feed switch was released before the
drilling depth was reached
Work table height (thickness)
The swivel stops were not set properly on
the ruler.
Keep feed switch engaged until the drilling
depth has been reached
Put work table underneath until a height of
24 mm has been reached
Check positions and stops and correct if
necessary
none
See chapter 7 - Ap-
pendix
none
Ruler not set properly Set ruler to the 0 point See point 1.1.3
Chips between the ruler and the work
piece
Remove dirt and chips none
Extension ruler is not attached properly Check ruler attachments and extension
- check spacing of both rulers
none
Swivel gear not engaged Allow index bolts to engage See point 2.1.3
Drillings are off
centre or in the wrong
position
6.1 - Error during drilling
