Page #11 background imageLoading...
Page #11 background image
Mechanical Installation
by Blum-Novotest 2010
11
Variant 3
Option Universal Holder
Fig. 3.4
Variant 4:
Option Front-Kit
Pls. refer to the appropriate data sheet
16
22
M6
Ø5,2
Klemmschraube
clamping screw
DIN913 M4 (2x)
M
d
= 1,5 Nm
Schwenkbereich
swivel range
8,5
27
19
6
0
°
P03.5600-010.080
P03.6600-010.250
