Mechanical Installation
8
by Blum-Novotest 2010
3. Mechanical Installation
CAUTION
Risk of short-circuit
Damage by chips
Never install cables and hoses without protection.
Cables and hoses must always be protected against chips
(protective hose, protection spring, cover etc.).
CAUTION
Risk of short-circuit
Damage of the cable by sharp edges
Pls. deburr the sharp edges on the cable bushing and
mount edge protection!
CAUTION
• The system should be placed protected from coolant
and chips.
• Distance between probe and receiver:
Pay attention to chap. 2.4
• Keep distance to other radio systems
