22
EN
1. Ceiling installation:
The distance from the electrical appliance to the surrounding walls should be
at least 200 mm, as shown in gure 1.
2. Double hanging ceiling installation:
Two electrical appliances are connected through a connecting frame installed
on the ceiling, as shown in Figure 2.
Note: The parts required for double installation are not included and must
be purchased separately.
