Installation diagram
Note: The parts shown may differ from the actual scope of delivery.
1
Solar Irrigation System
6
Hose plug
2
Filter
7
Anti-siphon
3
Y-shaped four-piece coupling
8
Hose (7/9 mm)
4
Four-piece coupling
9
Hose (4/6 mm)
5
Dropper
Important: Place the Anti-Siphon in a place higher than the water barrel.
