10
EN
SCOPE OF DELIVERY
Solar panel and
control unit
Hose (7/9) Hose (4/6) Y-shaped four-
piece coupling
1x 18 m 12 m 1x
Four-piece
coupling
Dropper Hose plug Filter
20x 40x 3x 1x
INSTALLATION
1 Cut the thick hose according to the depth of the water container and
insert the lter into the hose.
2 Insert the other end of the hose into the inlet of the control unit.
3 Cut another piece of thick hose according to the distance between the
control unit and the rst plant. Attach the Y-shaped four-piece coupling to
the end of the hose.
4 Then cut the thick and thin tubes according to the distances between the
plants. Use the hose connections to connect all the potted plants. Connect
one end of the tube to a drip and insert the drip into the potting soil. If the
plant is very large, use more than one dripper to get enough water.
5 Finally, insert the hose plugs into the open hose ends.
