HEX11WP-TX QUICK REFERENCE GUIDE
Contact: support@blustream.com.au | support@blustream-us.com | support@blustream.co.uk
03
RS-232 HDMI Infrared Cat 6 DC Power
HEX11WP-TX Example Schematic
HDMI Source
HDBaseT™ RX
Control Processor
Display
Compatible Blustream HDBaseT™ Matrix or Receiver product. *Technical performance is subject to the features supported on the connected HDBaseT™ device.
Optional PSU when not powered via HDBaseT™
