Blyss EL1716B - Page 22

22
Installation
1040 mm
Wall support
FLOOR
IMPORTANT : Please follow the safety advice set out on pages 3 to 5.
1000
160
500
Control panel
Switch ON/OFF Wall support
Slots
Wall bracket Locking hook
Hot air outlet
Slots + Slots +
locking hook locking hook
