OWNER’S MANUAL
THANK YOU VERY MUCH FOR PURCHASING THIS BMB
SPEAKERS SYSTEM. BEFORE USE, PLEASE READ
FOLLOWING INSTRUCTIONS THROUGH CAREFULLY
AND FAMILIARIZE YOURSELF WITH THE OPERATION
OF THE SYSTEM.
BEFORE USE
Operating Precautions
The maximum input power of these speakers is 500 W (at peak). Higher levels of input power may cause damage to the speaker system and so
take every precaution to keep the power down to the specifi cation.
Even if an amplifi er with a maximum output power of less than 500 W is employed, do not use the speakers with the volume turned up too high
or the sound distorted. This may damage the speakers.
Make sure that the amplifi er’s power switch is at the OFF position when connecting the speakers to the amplifi er.
Make sure that the amplifi er’s volume control is turned down to its lowest setting when the amplifi er’s power switch is set to the ON position.
CONNECTIONS
INSTALLATION
Make sure that you set the power switch on the amplifi er to the OFF position when connecting the speakers to the amplifi er.
Align the (–) and (+) polarities of the speakers with the (–) and (+) polarities of the left (L) and right (R) channels of amplifi er, and connect the
speakers to the speaker terminals on the amplifi er.
* If the polarities of the left and right speakers are not aligned properly, the quality of the reproduced sound, the ambience and the feeling of
direction will all be markedly impaired.
* When making the connections, take every precaution to prevent the speaker cords’ central cores from being shorted.
Installing the Speakers
Avoid installing the speakers in a location exposed to direct sunlight and high levels of humidity.
Avoid also locations in the vicinity of stoves and other sources of heat.
With a speaker system, the sound which is heard varies greatly according to the installation location. Bear in mind the following points in order to
derive the most enjoyment from music.
a) Install the speaker at the upper position than your ears level when you listen to the sound under normal listening conditions.
b) The best distance between the speakers is approx. 2 to 5 m.
c) The bass sounds fuller if the speakers are installed on a solid and stable stand of shelf, or if they are placed against a wall.
The bass sound will lose its impact if objects which do not refl ect the bass well enough are placed in front of the speakers.
If you plan to hang your speakers from the ceiling, contact a professional installer.
Caution:
If you want to suspend the CSX-850 from the ceiling, use adequate mounting hardware that can bear the load. In addition, be sure to secure the
mounting hardware onto a place of high-tensile strength using screws appropriate to the ceiling materials.
MAINTENANCE OF CABINET
When the cabinets are dirty, clean off the dirt with a soft cloth. If the dirt is engrained, moisten a soft cloth in cold or lukewarm water, wring it out, and
then wipe off the dirt. Never use thinners or alcohol since these substances can impair the fi nish of the cabinet. Also, avoid using insecticide and
other sprays near the speakers.
The CSX-850 features a multi-speaker confi guration based on the multidirectional method that is capable of delivering a dynamic sound widely
even in a spacious room. It comprises fi ve speakers: a woofer located in the center of the cabinet responsible for deep bass, a pair of squawkers
reproducing mid/high frequencies, and a pair of tweeters for high tones. The pairs of squawkers and tweeters are installed in the cabinet with specifi c
angles. In addition, the squawker units situated in the middle of the box can be vectored to any direction to support various environment conditions.
They are set by factory default to the standard position so as to create a sound fi eld all over the fl oor level in a big room.
1. Pull the right and left speaker grills fi rmly to remove them. (Each speaker grill has a set of safety catches on the upper and lower ends, which are
locked to the cabinet. You can easily release the lock to remove the grill by pulling hard the duct hole with a hand.)
2. Use a Phillips-head screwdriver to remove the four screws that hold the squawker to the cabinet.
Caution:
Do not unscrew the four screws that hold the squawker to its black platform. In addition, make sure never to remove the tweeters located above
the squawker; the tweeters are identical in appearance to the squawker units. Note that you can not change the direction of the tweeters.
3. Rotate the squawker with its black platform 180 degrees clockwise or counterclockwise so that it points signifi cantly outward, and then secure it
with the four screws. Make sure to secure at the same time a thin airtight gasket between the platform and the cabinet.
Caution:
Once you removed the screws, avoid pulling out, dropping or rotating more than 180 degrees the squawker unit, or the cable may be
disconnected from the unit.
4. Push the grills in place, pressing with a fi nger the safety lock catch located in the upper and lower ends of the grill in order that it may not
damage the cabinet.
Making Allowable Connections between Speakers and Your Amplifi er
(Ex. 4 Speakers)
Confi gure and wire the speakers so that the combined impedance falls within 6 to 32 Ω.
Note:
The specifi cation allows the combined impedance ranging 4 to 32 Ω, however, 4 Ω confi guration is not recommended; avoid it whenever possible.
If you want to expand the sound fi eld all over a big room, in stead of focusing on the fl oor level...
ACCESSORIES
Owner’s manual: 1 pc
About Multidirectional Method Speakers
When the CSX-850 create a sound fi eld in a higher
area than expected in a high-ceilinged room...
In stead of 180 degrees of rotation applied in step 3 mentioned above,
rotate to fi x the right and left squawkers 90 degrees counterclockwise so
that they point downward.
If you want to direct the sound fi eld to a higher
position than the speakers level (e.g. terrace theater)
In stead of 180 degrees of rotation applied in step 3 mentioned above,
rotate to fi x the right and left squawkers 90 degrees clockwise so that
they point upward.
