BME 37% Ultimate Ver 1.0 3/15/2004 Page 3
INTRODUCTION
Congratulations! You have just purchased an outstanding aerobatic aircraft in the form of the BME Aircraft
37% Ultimate Biplane. The Ultimate has long enjoyed a reputation of being one of the best flying RC aerobatic
designs in existence. This reputation was earned and well-proven over the years in what was perhaps the most
prestigious RC event in the world – the Tournament of Champions (TOC). The outstanding flight
characteristics of the Ultimate were recognized and demonstrated in the late 80's and early 90's when it was the
aircraft of choice for almost every TOC competitor and again in 2002 when the Ultimate was flown to 1
st
place
against the best pilots and RC aircraft in the world.
Until now the Ultimate has been readily available only in smaller sizes of 1.20 and below and most recently in
very large versions of 40% scale and above. To fill the large void of 100cc sized aircraft BME has introduced
the 37% Ultimate – just the right size to present well with the 40% monoplanes but a lot easier to handle than
the giants and a the perfect match for the new BME 110 Extreme engine!
SPECIFICATIONS
Wing Span 80.5"
Wing Area 2254 sq. in.
Weight 26-27 lbs. With
BME Extreme110
Wing Loading 26-28-oz./sq. ft.
Recommended Engine 100cc or Greater (lighter is better)
Construction Light Ply, Balsa, Foam & Fiberglass
Plug-in Wings Aluminum Spar Tubes
Plug-in Horizontal Stabs Aluminum Spar Tubes
Covering Monokote
Bottom Wing Incidence Zero (0) Degrees
Top Wing Incidence 1.5 Degrees Negative (preset by cabanes)
Engine Right Thrust Approximately 3 Degrees.
Engine Down Thrust 0 Degrees to +1 Degree
Elevator High Rates 20 degrees Up and Down
Elevator Low rates To Suit
Bottom Wing Aileron High Rates 25 Degrees Up and Down
Top Wing Aileron High Rates 20 Degrees Up and Down
Aileron Low Rates To Suit
Rudder Rates To Suit (rudder is very effective)
3D Rates Max All Surfaces and Adjust Down to Suit
Read through the instruction booklet and study the parts and photos to become familiar with the construction
before actually beginning work. The kit is highly prefabricated and the instructions detailed to guide you
through all major elements of the assembly processes.
Good Luck and Happy Flying!
