BMT 801 - 37. Fuel Tank Assembly; 38. Engine Mount; Clutch Assembly; 40. Engine Unit; Exhaust System Assembly

17 18
37
38
40
39
3x14mm x4
PA8167
Cap Screw
3x8mm x1
PA8166
Cap Screw
3.1x6x0.5mm
5.1x8x0.25mm
Washer
Washer
PA8021
PA8022
PA7098
PA8151
PA7098
PA8023
M3 Nut x4
5x10x4mm x2
PA0100
PA8142
PA8142
PA8142
PA8142
PA8155 : 13T
PA0100
PA8136
PA8137
PA0100
Ball Bearing
4x4mm x2
PA0068
PA0068
PA8119
PA8119
Set Screw
4x10mm x1
PA8164
F/H Screw
Engine Unit / Exhaust System Assembly
In-Line Muffler And Manifold AssemblyFuel Tank Assembly
Engine Mount / Clutch Assembly
PA8163
PA8164
4x8mm x4
PA8163
PA8152
PA8135
PA8130
PA8129
PA8131
F/H Screw
3x10mm x2
PA0142
PA0142
PA8052
PA8141
PA8052
PA8050
PA8051
PA0142
B/H Screw
4x8mm x2
O-Ring
PA7058
3x10mm x2
F/H Screw
PA8167
PA8166
PA8052
PA8052
PA7058
GP
GP
GP
GP
PA8050 : Fuel Tank 125CC
PA8051 : Fuel Tank 150CC
(OPTION)
4x8mm x4
Engine Screw
