S1000 01/2019 onwards
• Remove the front seat.
• Push rider's seat (1) at the seat cushion surface (arrow) forward.
• Remove bolt (2) .
• Lift rider's seat (1) at rear and remove.
• Begin by connecting one end of the red jump lead to the positive terminal of the
discharged battery and the other end to the positive terminal of the donor battery.
• Then connect one end of the black jump lead to the negative terminal of the donor
battery, and the other end to the negative terminal of the discharged battery.
• Start the engine of the vehicle with the discharged battery in the usual way; if the
engine does not start, wait a few minutes before repeating the attempt in order to
protect the starter motor and the donor battery.
• Disconnect the jump lead from the negative terminals first, then disconnect the
second lead from the positive terminals.
• Installing front seat.
