E90 General Vehicle Electrical
Legend for Anti-Theft Alarm System
Index Explanation Index Explanation
1
Driver's Door Lock Barrel
17
Door Contact, Driver's Door
2
Footwell Module (FRM)
18
Passenger's Door Contact, Left Rear and Right
Door
3
Direction Indicator Repeater, Right
19
Emergency Current Siren with Integrated Tilt
Alarm Sensor
4
Headlight, Right
20
Roof Functions Center (FZD)
5
Headlight, Left
21
Car Access System 2 (CAS2)
6
Direction Indicator Repeater , left
22
Hood Contact Switch
7
Tail Light, Right
23
Comfort Access (CA)
8
Tail Light, Left
DWA-Bus
DWA-bus (K-bus protocol)
9
Junction Box Electronics Control Module
(JBE)
CAS-Bus
K-bus (K-bus protocol)
10
Button, Trunk Lid, Exterior
K-CAN
Bodyshell CAN
11
Central Locking, Trunk Lid
Kl. 30
Terminal 30
12
Ultrasonic Passenger Compartment
Protection (USIS)
Kl. 31
Terminal 31
13
Anti-Theft Alarm System DWA-LED
FBD
Remote Control Services
14
Identification Transmitter
FBD ON
Remote Control Services ON
15
Rear Window Antenna
FBD OUT
Remote Control Services OUT
16
Remote Control Receiver
