BMW E90 - Page 77

77
E90 General Vehicle Electrical
Legend for Power Window - Circuit Diagram
Index Explanation Index Explanation
1
Driver’s door lock barrel
14
Car Access System 2 (CAS 2)
2
Footwell module (FRM)
15
Driver’s door switch cluster (SBFA
3
Power window motor with indirect anti-trapping
function, passenger’s side
16
Power window motor with indirect anti-trapping
function, driver’s side
4
Junction Box Electronics Control Module (JBE)
17
Door contact
5
Power window switch, front passenger’s side
K-CAN
Bodyshell CAN
6
Power window motor with indirect anti-trapping
function, rear right
KID.30
Terminal 30
7
Power window switch, rear right
KID.58
g
Terminal 58g
8
Power window switch, rear right
LIN-
Bus
Local interconnected network bus
9
Power window motor with indirect anti-trapping
function, rear left
FBD
Remote control services
10
Remote control
FBD
ON
Remote control services ON
11
Rear window antenna
FBD
OUT
Remote control services OUT
12
Remote control receiver
CAS-
Bus
K-Bus (K-Bus protocol
13
Comfort Access (CA)
