Workshop Exercise - Emergency Operation
With the proper repair instructions and instructor guidance,
perform the emergency closing procedure. The RHT should be
stowed in the trunk area before beginning the process.
If not already removed, remove rear trim as shown.
What special tools are required to open the closure cylinders
to unlock the rear module?
Use special tools to unlock rear module.
Open rear module by hand, lift from center of rear module
taking care not to damage plastic covers.
Before removing any latches or brackets, make sure to mark
bolts to help on reassembly.
Make sure when lifting roof module out of trunk well, have at
least 2 people to assist. Keep fingers clear of linkage to avoid
injury.
List all tools required to perform this emergency procedure:
Notes:
