E93 Complete Vehicle Workbook
73
Workshop Exercise - Hall Sensors and Microswitches
Using the available reference material and class vehicle, identify and locate all microswitches and Hall sensors on the vehicle.
Complete the exercise by filling in the chart below with the correct sensor/switch terminology.
Index Explanation Index Explanation
1 9
2 10
3 11
4 12
5 13
6 14
7 15
8
