E93 Complete Vehicle Workbook
87
Index Explanation Index Explanation
1
Closure cylinder
5
Outlet flaps for main pillars
2
Lock hook
6
Rear module mechanism
3
Rear roof shell locking roller
7
Rear roof shell
4
Rear module locking roller
