BMW F 800 GT User Manual

Affect of wheel size on
ABS
Wheel sizes greatly affect the
function of the ABS system. Es-
pecially the diameter and width
of the wheels are stored in the
control unit as the basis for all
necessary calculations. A change
in these sizes due to conversion
to wheels not installed as stan-
dard equipment can seriously af-
fect the control comfort of these
systems.
The sensor rings required for
wheel speed detection must also
match the control systems in-
stalled and may not be replaced.
If you want to equip your
motorcycle with different wheels,
please speak to a specialist
service facility, and preferably a
BMW Motorrad retailer. In some
cases the data stored in the
control units can be adapted to
the new wheel sizes.
TPC/RDC sticker
with Tire Pressure Monitor
(TPM)
OE
ATTENTION
Improper tire removal
Damage to the TPC/RDC sen-
sors
Inform a specialist service
facility or an authorized
BMW Motorrad retailer on the
fact that the wheel is equipped
with a TPC/RDC sensor.
On motorcycles equipped with
TPC/RDC, a corresponding
sticker is located on the wheel
rim in close proximity to the
TPC/RDC sensor.
Removing front wheel
Make sure ground is level and
firm and park motorcycle.
Remove screw 1 and take
wheel speed sensor out of
bore.
9
102
z Maintenance

BMW F 800 GT Specifications

General

Displacement	798 cc
Max Power	90 hp (66 kW) @ 8, 000 rpm
Max Torque	86 Nm (63 lb-ft) @ 5, 800 rpm
Transmission	6-speed
Seat Height	800 mm (31.5 inches)
Curb Weight	213 kg (470 lbs)
Fuel System	Electronic fuel injection
ABS	Standard
Fuel Capacity	15 l
Front Suspension	Telescopic fork
Engine Type	Liquid-cooled, 4-stroke, in-line two-cylinder
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 265 mm disc, single-piston caliper
