Push yellow button 4 forward
and at the same time push the
topcase lid up.
Closing topcase
Turn key in the topcase lock to
the vertical position.
Press down firmly on the top-
case lid to close.
Closing the carry handle
while the topcase lock is
horizontal can result in damage
to the locking tongue.
Make sure that the topcase lock
is vertical when you close the
carry handle.
Close carry handle 3.
The handle engages with an
audible click.
Turn the key in the topcase
lock to the horizontal position
and remove the key from the
lock.
Adjusting topcase volume
Open the topcase and remove
all its contents.
Engage pivot lever 1 at the
front limit position to set the
case to maximum volume.
Engage pivot lever 1 at the
rear limit position to set the
case to minimum volume.
Close the topcase.
8
85
z
Accessories
