Connecting battery to
motorcycle
First install the positive battery
cable 2 and cover with the pro-
tective cap 3.
Then install battery negative
lead 1.
Installing the seat ( 44).
Removing battery
Removing seat ( 43).
Disconnecting battery from
motorcycle ( 97).
Remove screw 1.
Unhook and lift up the holder 1
on the left.
Unloosen the holder from the
battery tray 2 on the right.
The holder is now only at-
tached to the wiring harness 3.
Push the holder and the wiring
harness to the right out of the
way.
You can now remove the bat-
tery.
Lift the battery 4 up and out.
Work it back and forth slightly if
it is difficult to remove.
Installing battery
Place the battery 4 in the bat-
tery compartment with the
positive terminal on the right
in the direction of travel.
8
98
z
Maintenance

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the BMW G 310 GS and is the answer not in the manual?

BMW G 310 GS Specifications

General IconGeneral
Displacement313 cc
Bore x Stroke80 mm x 62.1 mm
Maximum Torque28 Nm at 7, 500 rpm
Transmission6-speed
Fuel SystemElectronic fuel injection
Front SuspensionUpside-down fork, Ø 41 mm
ABSBMW Motorrad ABS
Seat Height835 mm
Wheelbase1, 420 mm
Engine TypeWater-cooled, single-cylinder, 4-stroke engine
Maximum Power34 hp (25 kW) at 9, 500 rpm
Front Brake300 mm disc, 4-piston caliper
Rear Brake240 mm disc, single-piston caliper
Fuel Capacity11.5 liters
Weight169.5 kg (unladen weight, DIN)
