BMW G 310 GS User Manual

If pressure points are not clearly
perceptible:
ATTENTION
Work on brake system not
in compliance with correct
procedure
Risk to operational reliability of
the brake system
Have all work on the brake sys-
tem undertaken by trained and
qualified specialists.
Have the brakes checked by a
specialist workshop, preferably
an authorised BMW Motorrad
dealer.
Checking front brake pad
thickness
Make sure the ground is level
and firm and place the motor-
cycle on its stand.
Turn the handlebars all the way
to the right.
The brake pads 1 can be seen
from the rear.
Visually inspect the brake pads
to ascertain their thickness.
Check the wear indicators 2.
Brake-pad wear limit,
front
min 1.0 mm (Friction lining
without carrier plate)
If the wear indicating marks are
no longer visible:
8
73
z Maintenance

BMW G 310 GS Specifications

General

Displacement	313 cc
Bore x Stroke	80 mm x 62.1 mm
Maximum Torque	28 Nm at 7, 500 rpm
Transmission	6-speed
Fuel System	Electronic fuel injection
Front Suspension	Upside-down fork, Ø 41 mm
ABS	BMW Motorrad ABS
Seat Height	835 mm
Wheelbase	1, 420 mm
Engine Type	Water-cooled, single-cylinder, 4-stroke engine
Maximum Power	34 hp (25 kW) at 9, 500 rpm
Front Brake	300 mm disc, 4-piston caliper
Rear Brake	240 mm disc, single-piston caliper
Fuel Capacity	11.5 liters
Weight	169.5 kg (unladen weight, DIN)
