G01�General�Vehicle�Electronics
1.�Exterior�Lights
8
Index Explanation
1 Digital�Motor�Electronics�(DME)
2 Electronic�transmission�control�(EGS)
3 Fuses�in�the�power�distribution�box,�front�right
4 Body�Domain�Controller�(BDC)
5 Fuse�in�the�Body�Domain�Controller
6 Rear�light�cluster,�right�outer
7 Rear�light�cluster,�right�inner
8 License-plate�light,�right
9 License-plate�light,�left
10 Rear�light�cluster,�left�inner
11 Rear�light�cluster,�left�outer
12 Additional�brake�light
13 Interference�suppression�filter
14 Light�switch
15 Hazard�warning�switch/Intelligent�Safety�button
16 Steering�column�switch�cluster�(SZL)
17 Rain-light-solar-condensation�sensor�(RLSBS)
18 Brake�light�switch
The�system�wiring�diagram�shows�the�basic�version�with�bulbs�and�LEDs�for�the�tail�light.
In�the�High�version,�all�light�functions�are�realized�with�LED�technology.
1.3.2.�Rear�light
On�the�G01,�2�different�rear�lights�are�installed�depending�on�the�headlight�version.
The�Basic�rear�light�is�used�on�vehicles�with�the�following�equipment:
• LED�headlights
• LED�headlights�with�cornering�lights.
The�High�rear�light�is�used�on�vehicles�with�the�following�equipment:
• Adaptive�full�LED�headlights.
In�the�Basic�rear�light,�only�the�tail�light�is�in�LED�technology.�Bulbs�are�used�for�all�other�light
functions.
In�the�High�rear�light,�all�light�functions�are�in�LED�technology.
