G01�General�Vehicle�Electronics
4.�Locking�and�Security�Functions
30
Index Explanation
1 Fuses�in�the�power�distribution�box,�front�right
2 Body�Domain�Controller�(BDC)
3 Fuse�in�the�Body�Domain�Controller
4 CAN�terminator
5 Fuses�in�the�rear�power�distribution�box
6 Tailgate�lift�drive
7 Tailgate�function�module�(HKFM)
8 Tailgate�contact�switch�in�the�tailgate�lock
9 Automatic�Soft�Close�drive
10 Button�for�closing�tailgate�(inner)
11 Button�for�tailgate�(outer)
12 Acoustic�warning�device�for�tailgate�activation
13 Luggage�compartment�light,�left
14 Luggage�compartment�light,�right
15 Remote�control�receiver�(FBD)
16 Switch�block,�driver's�door
17 Button�for�opening�tailgate
18 Power�window�motor,�driver's�side�front
19 Instrument�cluster�(KOMBI)
