G01�General�Vehicle�Electronics
1.�Exterior�Lights
3
Index Explanation
1 Left�fog�light
2 Right�fog�light
3 Left�headlight�with�Frontal�Light�Electronics�Left�(FLEL)
4 Right�headlight�with�Frontal�Light�Electronics�Right�(FLER)
5 Fuses�in�the�power�distribution�box,�front�right
6 Body�Domain�Controller�(BDC)
7 Fuse�in�the�Body�Domain�Controller
8 Turn�indicator�in�exterior�mirror,�right
9 CAN�terminator
10 Fuse�for�rear�right�power�distribution�box
11 Fuse�in�the�power�distribution�box,�battery
12 Ride-height�sensor,�rear�left
13 Turn�indicator�in�exterior�mirror,�left
14 Light�switch
15 Steering�column�switch�cluster�(SZL)
16 Hazard�warning�switch/Intelligent�Safety�button
17 Rain-light-solar-condensation�sensor�(RLSBS)
18 Ride�height�sensor,�front�left
The�system�wiring�diagram�shows�the�basic�version.�Depending�on�the�headlight�version,�different
components�are�installed�in�the�corresponding�headlight.
The�wiring�diagram�shows�the�turn�indicator�and�the�high�beam�headlight�with�bulbs.�Depending�on
the�headlight�version,�the�turn�indicator�is�designed�either�with�LED�technology�or�a�bulb.�A�halogen
bulb�or�LED�is�used�for�the�high�beam.
