G07�Complete�Vehicle
2.�Body
17
2.3.�Heating�and�air-conditioning�systems
Two�versions�of�the�integrated�automatic�heating/air�conditioning�system�(IHKA)�are�available�for�the
G07.�The�IHKA�regulated�on�the�air�side�is�based�in�part�on�the�G12�and�G01.�More�in-depth�topics
can�be�found�in�the�product�information�ST1501�G12�Climate�Control.
• 4/3-zone�IHKA�(standard�equipment)
• 5/4-zone�integrated�heating�and�air�conditioning�system�(option�SA�4NN).
From�a�technical�perspective�the�climate�control�is�divided�into�zones�(e.g.�driver,�front�passenger,
rear�passenger�compartment,�temperature...).�The�1st�digit�represents�the�number�of�individually
adjustable�temperature�zones,�while�the�2nd�digit�represents�the�number�of�zones�in�which�the�air
volume�is�separately�controllable.�On�the�G05�and�G07�the�heating/air�conditioning�display�is�fitted
between�the�center�air�vents�for�the�first�time.
Air�conditioning�control�panel�for�driver/front�passenger
Index Explanation
1 Lever�for�changing�the�airflow�direction
2 Knurled�wheel�for�steplessly�opening�and�closing�the�ventilation�outlets
3 Hazard�warning�switch
4 Display
5 Intelligent�Safety�button
6 Active�seat�ventilation/seat�heating,�right
7 Max.�cooling�on/off
8 Air�recirculation�function�on/off
9 Manual�air�distribution�regulation,�right
10 Automatic�program,�right
11 Temperature�adjustment,�right
