Technical data
Engine
Construction Air-/oil-cooled, twin-cylinder, 4-stroke boxer, single camshaft,
four valves per cylinder, central counterbalance shaft
Bore x stroke 101 mm x 73 mm
Capacity 1,170 cc
Max. output 113 hp (83 kW) at 7,500 rpm
Max. torque 115 Nm at 6,000 rpm
Compression ratio 12.0:1
Fuel/engine management Electronic intake pipe injection/BMS-K electronic engine
management with overrun fuel cut-off, twin-spark ignition
Emission control Regulated 3-way catalytic converter, compliant with EU-3
emission standard
Performance/fuel consumption
Max. speed Over 200 km/h
Consumption per 100 km
at a constant 90 km/h
4.1 litres
Consumption per 100 km
at a constant 120 km/h
5.5 litres
Fuel type Super plus unleaded 98 octane (RON); also runs on 95
octane (RON) and above due to automatic knock control
Electrics
Alternator 600-W generator
Battery 12 V/12 Ah, maintenance-free
Transmission
Clutch Hydraulically operated single-disc dry clutch
Gears 6-speed helical synchromesh gearbox
Drive Shaft drive
Chassis/brakes
Frame Tubular steel
Suspension, front Upside-down fork, adjustable rebound and compression
damping
Suspension, rear Forged aluminium swing-arm with BMW Motorrad Paralever;
Öhlins central strut, continuously adjustable spring preload,
adjustable rebound and compression damping
Travel, front/rear 160 mm/160 mm
Wheelbase 1,615 mm
Castor 95 mm
Steering head angle 61.4°
Wheels Cast aluminium
Rim dimensions, front 3.50 x 17"
Rim dimensions, rear 5.50 x 17"
Tyre, front 120/70 ZR 17
Tyre, rear 180/55 ZR 17
Brakes, front Double-disc brake system with 320-mm diameter
³ oating brake discs, 4-piston ² xed caliper
Brakes, rear Single-disc brake (265-mm diameter), double-piston
³ oating caliper
Dimensions/weight
Seat height 890 mm (can be reduced to 860 mm by adjusting
the telescopic fork tubes and length-adjustable strut)
Unladen weight,
fully fuelled/road-ready*
199 kg
Dry weight** 179 kg
Max. permitted weight 380 kg
Usable tank volume 13 litres
Of which reserve 2 litres
Width (inc. mirrors) 922 mm
* As de² ned in EU directive 93/93/EEC, ² lled with all operating ³ uids to at least 90% of usable tank capacity.
** Unladen weight without operating ³ uids.
Accessories
HP carbon engine cover
HP carbon cylinder head covers, left and right
HP forged wheel, front (3.50 x 17")
HP forged wheel, rear (3.50 x 17")
Tank rucksack, waterproof
Rear bag, splashproof
High seat (910 mm)
Pillion foot pegs
Foot peg pads
Handlebar padding
On-board toolkit
Paddock stand
Optional equipment
BMW Motorrad ABS (disengageable)
bmw-motorrad.com/equipment
26 – 27 | HP2 Megamoto
Aura White/Magnesium Matt Metallic
