If the remote control is not detected, slightly
change the position of the remote control and re‐
peat the procedure.
Integrated key
General information
The driver's door can be locked and unlocked
without remote control using the integrated key.
Safety information
WARNING
Unlocking from the inside is only possible with
special knowledge.
Persons who spend a lengthy time in the vehi‐
cle while being exposed to extreme tempera‐
tures are at risk of injury or death. Do not lock
the vehicle from the outside when there are
people in it.
NOTE
The door lock is permanently joined with the
door. The door handle can be moved. When
pulling the door handle with the integrated key
inserted, paint or the integrated key can be
damaged. There is a risk of damage to prop‐
erty. Remove the integrated key before pulling
the outside door handle.
Removing
Press the button, arrow 1, and pull out the
integrated key, arrow 2.
Locking/unlocking via the door lock
1.
Remove lid on the door lock.
To do this, slide the integrated key into the
opening from below and unlock the lid.
2. Unlock or lock the door lock using the
integrated key.
The other doors must be unlocked or locked
from the inside.
Seite 74
CONTROLS
Opening and closing
74
Online Edition for Part no. 01402989267 - II/18
