BMW M3 2001 - Indicator and Warning Lamps

19n
Index Data Technology Repairs Car care Controls Overview
Instrument cluster
1 Fuel gauge with indicator lamp for
fuel reserve 70
2 Turn signal indicator 22
3 Speedometer
4 Indicator lamp for:
> Battery charge current 20
> High beams 22
> Engine oil pressure/Engine oil
level 20, 21
5 Tachometer and engine oil
temperature gauge 69, 69
6 Engine coolant temperature gauge
with "Coolant temperature too high"
indicator 70
7 Indicator and warning lamps
(clockwise) for:
> Parking brake/Brake hydraulic
system/Cornering Brake Control
(CBC) 20
> Antilock Brake System
(ABS) 21
> Brake pads 21
> Tire Pressure Warning
(RDW) 20, 22
> Airbags 21
> Please fasten safety belts 21
> Cruise control 22
8 Set button for the clock 73
9 Indicator lamp for Dynamic Stability
Control (DSC) 22
10 Indicator for:
> Odometer 69
> Trip odometer 69
> Clock 73
> Service Interval 71
Indicator for computer, operation
using the turn signal lever, refer to
page 72:
> Clock
> Outside temperature
> Average fuel consumption
> Crusing range
> Average speed
11 Indicator for Check Control 72
12 Trip odometer, reset to zero 69
13 Indicator and warning lamps
(clockwise) for:
> Fog lamps 22
> Add washer fluid 22
> Coolant level 22
> Electronic Throttle Control
(EML) 22
> Service engine soon 22
You can have the outside temper-
ature and distance traveled shown
in other units of measurement.
<
