11 2 110
(engine dismantled)
M52 B20/M52TU B20 M54 M22
Fig. 97: Identifying Injection Nozzles
Courtesy of BMW OF NORTH AMERICA, INC.
M52 B25/B28 S52 M52TU B25/B28 M54 B25/B30 M56
NOTE: Injection nozzles for cooling the pistons are installed in the bores of bearing
seats 2 to 7.
NOTE: Injection nozzles for cooling the pistons are installed on the underside of the
cylinder between the bearing seats.
2006 BMW X5 30i
2004-2006 ENGINE Engine Mechanical - Repair Instructions - X3 & X5 (M54)
sábado, 2 de octubre de 2021 11:25:51 p. m. Page 102 © 2011 Mitchell Repair Information Company, LLC.
