Fig. 175: Removing Drive Belt
Courtesy of BMW OF NORTH AMERICA, INC.
Installation:
Check drive belt for coolant and oil residues, replace if necessary.
Install drive belt, make sure it is correctly positioned on belt pulleys.
CAMSHAFT
11 31 001 REPLACING CAMSHAFT (M52TU / M54 / M56)
Special tools required:
 00 9 250
 11 2 300
 11 3 240
 11 3 244

11 3 250
IMPORTANT: Drive belt must be replaced if fouled with hydraulic fluid.
