Courtesy of BMW OF NORTH AMERICA, INC.
VARIABLE CAMSHAFT TIMING
11 36 010 REMOVING AND INSTALLING OR REPLACING DOUBLE VANOS ADJUSTMENT
UNIT (M52TU / M54 / M56)
Special tools required:
00 9 250
11 2 300
11 3 240
11 3 450
11 4 220
11 6 170
Necessary preliminary tasks:
Remove intake filter housing with air -mass flow sensor
Remove fan impeller with fan clutch and fan cowl
E60: Remove fan cowl with electric fan
Remove cylinder head cover, refer to 11 12 000 REMOVING AND INSTALLING, SEALING
CYLINDER HEAD COVER (M52TU / M54 / M56)
Remove spark plugs, refer to 12 12 011 REPLACING ALL SPARK PLUGS
E85 only:
Remove radiator cover
Drain coolant from radiator, refer to 17 00 005 DRAINING OFF AND TOPPING UP COOLANT
(M54)
Removal:
Removal of double VANOS adjustment unit is described separately from installation. Assembly sequence for
removal and installation is different.
Detach plastic cover for inlet camshaft.
NOTE: Protect drive belt against emerging coolant.
Remove right coolant hose
Remove solenoid valve for exhaust side, refer to 11 36 575 REPLACING
SOLENOID VALVE FOR EXHAUST SIDE ON VANOS ADJUSTMENT UNIT
2006 BMW X5 30i
2004-2006 ENGINE Engine Mechanical - Repair Instructions - X3 & X5 (M54)
sábado, 2 de octubre de 2021 11:25:55 p. m. Page 321 © 2011 Mitchell Repair Information Company, LLC.
