Fig. 393: Locating Monitor Sensors
Courtesy of BMW OF NORTH AMERICA, INC.
Unclip cable from holder. Disconnect plug connection. Unclip cable on rear side of engine from cable guide.
Remove monitor sensor from cylinders 1 to 3. Refer to 11 78 611 REPLACING OXYGEN MONITOR
SENSOR (CYLINDERS 1-3).
