Fig. 44: Attaching Dial Gauge
Courtesy of BMW OF NORTH AMERICA, INC.
NOTE: Max. permissible tilt clearance, refer to ENGINE - TECHNICAL DATA .
NOTE: If tilt clearance is excessive, valve guide is reamed out and a repair valve with a
larger shaft diameter is installed.
2006 BMW X5 30i
2004-2006 ENGINE Engine Mechanical - Repair Instructions - X3 & X5 (M54)
sábado, 2 de octubre de 2021 11:25:51 p. m. Page 49 © 2011 Mitchell Repair Information Company, LLC.
