Fig. 47: Checking Flatness Of Cylinder Head Sealing Surface
Courtesy of BMW OF NORTH AMERICA, INC.
Deviation from flatness max. 0.05 mm.
NOTE: Machining limit. Refer to ENGINE - TECHNICAL DATA .
2006 BMW X5 30i
2004-2006 ENGINE Engine Mechanical - Repair Instructions - X3 & X5 (M54)
sábado, 2 de octubre de 2021 11:25:51 p. m. Page 52 © 2011 Mitchell Repair Information Company, LLC.
