00 0 201
00 0 202
00 0 204
00 0 208
Assemble special tool 00 0 200 with special tools 00 0 201 / 00 0 202 / 00 0 208 and fit.
Fig. 56: Installing Special Tool On Engine
Courtesy of BMW OF NORTH AMERICA, INC.
Secure special tool 00 0 200 to front suspension eye on engine.
Tighten the screws (1 and 2).
NOTE: To remove the oil sump, you must lower the front axle support. There is no
need to perform a front axle alignment check.
NOTE: The supports (1) of special tool 00 0 208 must rest on the bolt connection of
both side walls.
2006 BMW X5 30i
2004-2006 ENGINE Engine Mechanical - Repair Instructions - X3 & X5 (M54)
sábado, 2 de octubre de 2021 11:25:51 p. m. Page 61 © 2011 Mitchell Repair Information Company, LLC.
