Unfasten engine speed sensor.
Fig. 68: Identifying Engine Speed Sensor
Courtesy of BMW OF NORTH AMERICA, INC.
Remove vibration damper. Refer to 11 23 010 REMOVING AND INSTALLING OR REPLACING
VIBRATION DAMPER (M52TU / M54 / M56).
Version where vibration damper and hub are two parts: Remove hub for vibration damper.
Remove oil sump. Refer to 11 13 000 REMOVING AND INSTALLING, SEALING OR REPLACING
OIL SUMP (M52TU / M54 / M56).
Drive out dowel pins from timing case cover towards rear. (Mandrel diameter less than 5 mm)
2006 BMW X5 30i
2004-2006 ENGINE Engine Mechanical - Repair Instructions - X3 & X5 (M54)
sábado, 2 de octubre de 2021 11:25:51 p. m. Page 73 © 2011 Mitchell Repair Information Company, LLC.
