Fig. 72: Identifying Sealing Surfaces
Courtesy of BMW OF NORTH AMERICA, INC.
Drive alignment pins into timing case cover until they protrude approx. 2 to 3 mm.
Secure new seals to timing case cover with a little grease.
2006 BMW X5 30i
2004-2006 ENGINE Engine Mechanical - Repair Instructions - X3 & X5 (M54)
sábado, 2 de octubre de 2021 11:25:51 p. m. Page 77 © 2011 Mitchell Repair Information Company, LLC.
