Fig. 78: Tightening Screw Connection For Timing Case Cover
Courtesy of BMW OF NORTH AMERICA, INC.
Replace radial seal in lower timing case cover. Refer to 11 14 141 REPLACING RADIAL SEAL IN
LOWER TIMING CASE COVER.
Assemble engine.
11 14 141 REPLACING RADIAL SEAL IN LOWER TIMING CASE COVER
Special tools required:
11 2 380
11 2 383
11 2 385
11 3 280
Remove vibration damper. Refer to
11 23 010 REMOVING AND INSTALLING OR REPLACING
NOTE: This repair instruction is valid for the following engines:
M50/M52/M52TU/M54/M56
S52
2006 BMW X5 30i
2004-2006 ENGINE Engine Mechanical - Repair Instructions - X3 & X5 (M54)
sábado, 2 de octubre de 2021 11:25:51 p. m. Page 83 © 2011 Mitchell Repair Information Company, LLC.
