Model 670C Berkeley Nucleonics Corp. 12 of 96
The following list describes some of the key features of the Model 670C Series
• High resolution, high sampling rate: 16 Bits, 600 MS/s
• Best output frequency vs amplitude trade off: up to 180MHz, up to 12V voltage window
• 2 operating modes in the same instruments: Function Generator and Arbitrary Waveform
Generator
• Very long memory: up to 256MSamples per channel
• Mixed signal generation: 2/4 analog outputs + 8 digital outputs (with Model 670C-DIG8)
• Simple touch screen user interface to create complex waveforms scenarios just in few screen
touches
• Large 7”, 1024x600 capacitive touch LCD
• Touchscreen or Keypad data entering
• Windows 10 operating system
• USB and LAN interfaces
• Compact case size with the possibility of rack mounting in 3U
Unpack the instrument and check that you received all items listed in the Package Content paragraph.
NOTE. The instrument does not ship with a product software CD. To reinstall the product software,
follow the instructions in the paragraph “Obtaining the Latest Software Releases” to get the latest
software release and the instructions in the paragraph “Install TrueArb Application” to install the
application.
CAUTION. To ensure proper cooling, keep sides of the instrument clear of obstructions.
Place the instrument on a cart or bench, observing clearance requirements:
• Top: 20 mm (0.8 in)
• Left and right side: 150 mm (5.9 in)
• Bottom: 20 mm (0.8 in)
• Rear: 75 mm (3 in)
To Next Page
