Model 670C Berkeley Nucleonics Corp. 7 of 96
This section contains information and warnings that must be observed to keep the instrument operating
in a correct and safe condition. You are required to follow generally accepted safety procedures in
addition to the safety precautions specified in this section.
Where the following symbols appear on the instrument’s front or rear panels, or in this manual, they
alert you to important safety considerations.
This symbol is used where caution is required. Refer to the accompanying information or
documents in order to protect against personal injury or damage to the instrument.
This symbol warns of a potential risk of shock hazard.
This symbol is used to denote the measurement ground connection.
This symbol is used to denote a frame or chassis connection.
This symbol is used to denote a safety ground connection.
On (Supply). This is the DC power connect/disconnect switch at the back of the
instrument.
Off (Supply). This is the DC power connect/disconnect switch at the back of the
instrument.
This symbol is used to denote Power. It is located on the front panel and denotes
Power On/Off status of the instrument.
This symbol is used to denote Direct Current.
This symbol is used to denote that the device connectors are sensitive to electrostatic
discharge
