S250 Bobcat Loader
SA-5 Operation & Maintenance Manual
DIAGNOSTICS SERVICE CODES (CONT’D)
Number Codes List
CODE CODE
01-16 Air filter not connected 11-05 Seat bar sensor short to battery
01-17 Air filter plugged 11-06 Seat bar sensor short to ground
02-16 Hydraulic charge filter not connected 12-21 Front auxiliary PWM switch out of range high
02-17 Hydraulic charge filter plugged 12-22 Front auxiliary PWM switch out of range low
12-23 Front auxiliary PWM switch not in neutral
03-09 Battery voltage low
03-10 Battery voltage high 13-05 Fuel shut-off hold solenoid short to battery
03-11 Battery voltage extremely high 13-06 Fuel shot-off hold solenoid short to ground
03-14 Battery voltage extremely low 13-07 Fuel shut-off solenoid open circuit
03-22 Battery voltage out of range low
14-02 Fuel shut-off pull solenoid error ON
04-09 Engine oil pressure low 14-03 Fuel shut-off pull solenoid error OFF
04-14 Engine oil pressure extremely low
04-15 Engine oil pressure shutdown level 15-02 Traction lock pull solenoid error ON
04-21 Engine oil pressure out of range high 15-03 Traction lock pull solenoid error OFF
04-22 Engine oil pressure out of range low
16-05 Traction lock hold solenoid short to battery
05-09 Hydraulic charge pressure low 16-06 Traction lock hold solenoid short to ground
05-14 Hydraulic charge pressure extremely low 16-07 Traction lock hold solenoid open circuit
05-15 Hydraulic charge pressure shutdown level
05-21 Hydraulic charge pressure out of range high 17-05 Hydraulic lock valve solenoid short to battery
05-22 Hydraulic charge pressure of range low 17-06 Hydraulic lock valve solenoid short to ground
17-07 Hydraulic lock valve solenoid open circuit
06-10 Engine speed high
06-11 Engine speed extremely high 18-05 Spool Lock Solenoid short to battery
06-13 Engine speed no signal 18-06 Spool Lock Solenoid short to ground
06-15 Engine speed shutdown level 18-07 Spool Lock Solenoid open circuit
06-18 Engine speed out of range
19-02
Bucket position solenoid error ON
07-10 Hydraulic oil temperature high
19-03
Bucket position solenoid error OFF
07-11
Hydraulic oil temperature extremely high
07-15
Hydraulic oil temperature shutdown level
20-02
Two-speed solenoid error ON
07-21
Hydraulic oil temperature out of range high
20-03
Two-speed solenoid error OFF
07-22
Hydraulic oil temperature out of range low
21-02 Glow plug error ON
08-10
Engine coolant temperature high 21-03 Glow plug error OFF
08-11
Engine coolant temperature extremely high
08-15
Engine coolant temperature shutdown level 22-02 Starter error ON
08-21 Engine coolant temperature out of range high
22-03
Starter error OFF
08-22 Engine coolant temperature out of range low
23-02
Rear base solenoid error ON
09-09 Fuel level low 23-03 Rear base solenoid error OFF
09-21 Fuel level out of range high
09-22 Fuel level out of range low 24-02 Rear rod solenoid error ON
24-03 Rear rod solenoid error OFF
