S250 Bobcat Loader
VII Operation & Maintenance Manual
MACHINE IDENTIFICATION
GRAB
HANDLES
OPERATOR SEAT
with SEAT BELT &
SEAT BAR
TILT
CYLINDERS
†BUCKET
STEPS
◆ REAR AUXILIARY
QUICK COUPLERS
LIFT ARM
*TIRES
REAR
GRILL
LIFT
CYLINDER
BUCKET
STEPS
FRONT AUXILIARY
QUICK COUPLERS
LIFT ARM
SUPPORT DEVICE
TAIL
LIGHT
REAR
DOOR
REAR
LIGHT
● OPERATOR CAB
(ROPS / FOPS)
◆ Optional or Field Accessory (Not Standard Equipment)
✽ TIRES - Tires shown may not be standard. The machine is factory equipped with standard tires. Other tires are available.
✝ Bucket - Several different buckets and other attachments are available for this machine.
● ROPS, FOPS - Roll Over Protective Structure, per SAE J1040 and ISO 3471, and Falling Object Protective Structure per
SAE J1043 and ISO 3449, Level I. Level II is available.
FRONT
LIGHTS
