124 S450 Operation & Maintenance Manual
OPERATING PROCEDURE (CONT’D)
Levelling The Ground Using Float (SJC – ‘ISO’ Pattern)
Figure 160
Press and hold the Float button (Item 1) while the joystick
is in neutral. While lowering the lift arms (Item 2)
[Figure 160], release the Float button.
Tilt the bucket forward (Item 3) [Figure 160] to change
the position of the cutting edge of the bucket.
With the bucket tilted farther forward, there is more force
on the cutting edge and more loose material can be
moved.
Drive backward to level loose material.
To disengage, press the Float button again or raise the lift
arms (Item 4) [Figure 160].
IMPORTANT
Never drive forward when the hydraulic control for lift
arms is in float position.
I-2005-1285
2
3
4
NA3052
1
NA1141A
